Design # 1: Modern Eco House-Japanese Zen Garden


Minimalist Modern Eco House design by Romain Demerville
Japanese Zen Garden design by Benedict Martin Caliwara
Rendered by Benedict Martin Caliwara
Zen Garden Area: 36 sqm.
Hardscape Elements: sand/ gravel, stone/boulders, lighting features
Softscape Elements: tropical plants

MODERN ECO HOUSE: MSDP

ZEN GARDEN : PLAN

ZEN GARDEN: PLAN

ZEN GARDEN: PERSPECTIVE 1 (WF: Sketchup+Kerkythea+Photoshop+Picasa)

ZEN GARDEN: PERSPECTIVE 2 (WF: Sketchup+Kerkythea+Photoshop+Picasa)

ZEN GARDEN: PERSPECTIVE 3 (WF: Sketchup+Kerkythea+Photoshop+Picasa)

ZEN GARDEN: PERSPECTIVE 4- NPR (WF: Sketchup+Cartoon Generator+Picasa)

ZEN GARDEN: PERSPECTIVE 5- NPR (WF: Sketchup+Fotosketcher+Cartoon Generator+Picasa)


Sunday, September 27, 2015

Music from the South: Maguindanaon Traditional Music (SketchUp+Audio Presentation)



The social nature of Filipinos as being communal is evident in different musical traditions. This idea is generally reflected in Maguindanaon music culture which involves such constant social interaction through ensemble playing. Thus, being able to interact with other people provides a sense of belonging which in turn increases self-fulfillment and self-satisfaction through music making.

The Maguindanaon instruments are typically crafted from wood and metal in a combination of geometric-curves, linear and arc form patterns. These patterns exhibit the Maguindanaon culture. In Maguindanao for instance, the kulintang instrumental frame can be decorated with highly ornamental designs commonly known as okir or okkil motif (intricate Islamic art form.)

In order to depict the intricacy and detailed art work of Maguindaon culture manifested in their musical instruments, I made some 3-D visualizations of Kulintang instrumental ensemble as well as kudyapi (solo instrument.) The visualizations were rendered in Non-photorealistic style using Sketchup, Photoshop and Picasa.

Kulintangan Instruments


1. Kulintang Ensemble

Perhaps the most widely performed instruments of the Maguindanaon are those which comprise of gong ensemble called palabunibunyan. This ensemble consists of the kulintang, a set of eight small gongs of graduated sizes, gandingan a set of four narrow-rimmed gongs, one or two agongs which are large gongs with wide rims, a drum called dabakan and a babandil which is usually a narrow-rimmed gong with shallow boss.

The musical pieces of the palabunibunyan are usually played in sets of three following prescribed sequence of binalig, sinulog and tidtu. A fourth piece called tangunggo is traditionally performed at rituals.



Kulintangan Musical Instruments


2. Kulintang a Tamlang

Bamboo version of kulintangan musical instruments.

A Tamlang


A Tamlang



3. Saronay (kulintang a tiniok)

Saronay is a type of Philippine metalophone with eight tuned knobbed metal plates strung together via string atop a wooden antangan (rack). Kulintang a tiniok is a Maguindanaon term meaning “kulintang with string” but they also could call them kulintang a putao, meaning “kulintang of metal.”

Saronay


4. Maguindanaon Solo Music (Kudyapi)

The kutyapi or kudyapi is a two-stringed lute with eight movable frets.

Kudyapi


Kulintang Music: Sample Audio/ Video


video

video


video



video

video

video



Wednesday, August 26, 2015

Making A Digital Watercolor Presentation: Sketchup Tutorial (NPR Style)



One of the fastest way and effective solution for design presentation is rendering your 3-D work(s) through Digital Watercolor style. This particular visualization can be categorized under Non-photo-realistic rendering (NPR) style, which differs from Photo realistic rendering. Technically, photo-realistic rendering aims to reconstruct realism using different render-engine software. In contrast, NPR style aims to present a more imaginative visualization of the actual scene. Here in this tutorial, I will present step-by-step procedures on how to make digital watercolor visualization using Sketchup, Fotosketcher, Photoshop and Picasa.


STEP 1. Open your skp file. Here is the original SketchUp model, view in perspective mode. As you notice, most areas are left uncolored. This is primarily because we want to achieve a more balanced watercolor effect. We don’t want to overpower the Sketchup color materials from the watercolor image texture when we go to layering procedure in Photoshop.

STEP 2. Group your model(s) into two main groups (main scene and entourage). Here, select the model(s)> press the right click button> select Make group. This will enable us to hide and unhide the selected groups when exporting our scene into 2D images.

STEP 3. For the main scene, set your SketchUp models to monochrome style with shadows turned on. Under the edge style option check the edges, profiles, depth cue and extensions.

STEP 4. Export the first group model(s). To do that, go to File> Export> 2D Graphic and save in JPEG format.

Here is the result

STEP 5. Hide the selected model (main scene). To do that, select all> hold shift and click the entourage group> right click on the main model> select hide.

STEP 6. For the entourage, Set-up your SketchUp model with default styles such as shaded with textures and edges. Disable the shadows. Export the second group model into 2D image.

Here is the result

STEP 7. Open all the exported images in Photoshop> set the blend mode to multiply> adjust the opacity with (80-90% value)
Add more watercolor texture and entourage to your scene. Below are some watercolor texture and entourage samples.



Groundcover (watercolor)

Flowers (watercolor)

Shrubs (watercolor)

Flag

Watercolor Textured Paper

STEP 8. Layer all the watercolor images in Photoshop except for the textured paper. Adjust the blend mode to multiply with (70-80% opacity). In order to fit all the images, select/ transform each layered image by pressing ctrl+T or (go to edit> transform> choose any of the following transform command. Erase all the excess colors. Save your work in JPEG format.

Here is the result

STEP 9. After we have completed layering all the entourage in Photoshop, were ready to apply the watercolor effects using Fotosketcher. Open your last image in Fotosketcher and select watercolor style ‘Painting 5’. Save image in JPEG format.

Here is the result

STEP 10. Again, using the Photoshop, open the last edited image and the watercolor texture paper. Set the blend mode to multiply. Adjust the opacity with 70-80% value. Save image in JPEG format.

STEP 11. To enhance the image with more authentic watercolor style we will edit the image using Picasa. Follow the procedure/ settings: Sharpen the Image> set to Orton mode> set to HDR mode> adjust the shadows and temperature.

Final Render Output

Thank you for reading. I hope you can use this technique (NPR style watercolor rendering) for your future projects and presentation.



Saturday, August 22, 2015

SKETCHUP: 3-D CHALLENGE (MY PROFESSIONAL PORTFOLIO AND COMPETITION)


Joining a competition is not just to win a prize; but to gain knowledge and to be able to improve your skills through these experiences.


1. SKETCHUP 3-D CHALLENGE

3-D Challenge is an online 3-D competition organized by the “Sketchup Texture” group which aims to promote community interaction among Sketchup users in a professional manner. This 3-D Challenge is an opportunity to expose, educate and improve the skills of all 3-D artists in the international level.


Here, the participants were tasked to modify a given 3-D model and enhance the rendering presentation using Sketchup. All participants were allowed to use any supplementary software for the digital rendering process. In terms of rules and regulation, the participants were required to register first in the 3-D Challenge official website before they could submit their entries.


1.1 3D CHALLENGE (DECEMBER 2014-JANUARY 2015)_SKT 3D CHALLENGE ARCH-VIZ INTENATIONAL RENDER CONTEST_MODERN OFFICE BUILDING

For this challenge, I was able to submit three entries, rendered in various styles (two photorealistic and one non-photo-realistic (NPR) style. Below are my complete art work entries with work in progress (WIP) detail(s).


1.1.2 WORK IN PROGRESS

1. Modern Office Building (Original Sketchup Model by Quốc Hữu Trần)


2. Test render using Kerkythea


3. Modifying the model scene and finding the right perspective.


4. Test render model scene 1 using Kerkythea


5. Modified building (Test render using Kerkythea)


6. Importing all 2-D and 3-D entourage in Sketchup


7. Test render water material (Day time/Night time render) using Kerkythea


8. Kerythea rendering process


9. Raw render (Kerkythea)


10. Post-production process done using Photoshop and Picasa


1.1.2 MY 3-D CHALLENGE ENTRIES



ENTRY 1: UMAGANG KAY GANDA (Morning Sky Gazing)



ENTRY 2: DAPIT-HAPON (City Skyline)



ENTRY 3: TAKIPSILIM (Sunset Sky Gazing)

Model Credit: Sketchup Texture


1.2. 3-D CHALLENGE (AUGUST 2014)_MODERN ECO HOUSE


Regarding this particular challenge, I was unfortunate because I wasn’t able to submit all my entries in time. However, despite of these circumstances, I still do some renders for practice to improve my skills.


ART WORK 1: Eco House (Daytime Scene)/ WF: Sketchup8+Kerkythea+Photoshop+Picasa/ 1600x900 resolution



ART WORK 2: Eco House (Poster)/ WF: Sketchup8+Kerkythea+Photoshop+Picasa



ART WORK 3: Eco House (Sunset Scene)/ WF: Sketchup8+Kerkythea+Photoshop+Picasa



ART WORK 4: Eco House (NPR Compilation)/ WF: Sketchup8+Kerkythea+Photoshop+Picasa



ART WORK 5: Eco House (NPR) Original/ WF: Sketchup8 +Photoshop+Picasa



ART WORK 6: Eco House (NPR) Cross Process/ WF: Sketchup8 +Photoshop+Picasa



ART WORK 7: Eco House (NPR) Sepia/ WF: Sketchup8 +Photoshop+Picasa



ART WORK 7: Eco House (NPR) B&W/ WF: Sketchup8 +Photoshop+Picasa



ART WORK 9: Eco House (NPR) Digital Water Color/ WF: Sketchup8 +Photoshop+Picasa

Model Credit: Sketchup Texture





2. ENAU 3-D COMPETITION_MS HOUSE

I do not consider myself a participant for this particular competition as I discovered the announcement too late. However, I still downloaded the file from ENAU FB group containing skp file, to do some rendering practice. Below are the results.




1. MS HOUSE (Raw render 1)/ WF: Sketchup8+Kerkythea



2. MS HOUSE (Raw render 2)/ WF: Sketchup8+Kerkythea



3. MS HOUSE/ WF: Sketchup8+Kerkythea+Photoshop+Picasa

4. MS HOUSE (Cross Process)/ WF: Sketchup8+Kerkythea+Photoshop+Picasa




5. MS HOUSE (B&W)/ WF: Sketchup8+Kerkythea+Photoshop+Picasa



6. MS HOUSE (NPR)/ WF: Sketchup8+Kerkythea+Photoshop+Fotosketcher+Picasa


7. MS HOUSE (BLUE INK)/ WF: Sketchup+Kerkythea+Photoshop+Fotosketcher+Picasa


Model Credit: ENAU



It was rewarding for me to be part of these 3-D challenge events. It is very good to know that there are many groups that organize such 3-D competition online which encourage all 3D artist, sketchup-enthusiast, professionals and students to create more art works.
